Garrett GTX4088R Dual Ball Bearing Turbo

Garrett GTX4088R Dual Ball Bearing Turbo

PRODUCT DESCRIPTION:

New GTX4088R dual ball bearing turbo with ultra high flow compressor wheel and featuring Garrett 11-Blade technology. 850HP potential flow.

Includes Turbine Housing. Choose from T4 Inlet, T3 Inlet, or V-band Inlet. 3' V-band Outlet.

PRODUCT SPECIFICATIONS:

Compressor Wheel Inducer: 65.0mm
Compressor Wheel Exducer: 88.4mm
Compressor Wheel Trim: 54
Turbine Wheel Inducer: 77.0mm
Turbine Wheel Exducer: 68.0mm
Turbine Wheel Trim: 78
Standard compressor housing is T04H Frame with 4' inlet, 2.5' outlet, and built-in & machined anti-surge.

TURBINE HOUSING OPTIONS:

T4 Inlet, 3' V-band Outlet (.85, .95, or 1.06 A/R)
T3 Inlet, 3' V-band Outlet (.89, .99, or 1.11 A/R)
V-band Inlet optional, 3' V-band Outlet. Available in .89, .99, or 1.11 A/R.

APPLICATION NOTES:

Uses same oil and coolant fittings as the standard GT4088R turbo

Applicable Garrett Part Numbers: 825614-5002S, 825614-5004S, 825614-5005S, 803614-2, 803614-4, 803614-5, 751450-0021, 751450-21

Normally In Stock, Shipping Daily!
