Garrett GT2560R Dual Ball Bearing Turbo - Compact - w- V-band Turbine Housing
782.10€
895.50€
Sold By: Baltic Turbo Motors
SKU: 466541-5001S
Categories: Performance Parts
Garrett GT2560R Dual Ball Bearing Turbo - Compact - w- V-band/V-Band Turbine Housing
PRODUCT DESCRIPTION:
Dual Ball Bearing GT2560R (aka GT28R) Turbo assembly with V-band Inlet and V-band Outlet turbine housing in .64 A/R. Includes compressor housing outlet adapter (3 bolt to 2' diameter outlet).
Excellent response turbo for 2-4 Cylinder applications - 150-280HP
This unit is usually in stock and ships withing 1-2 days.
PRODUCT SPECIFICATIONS:
310HP Flow capacity
Compressor Wheel Inducer: 46.5mm
Compressor Wheel Exducer: 60.1mm
Compressor Wheel Map: Maps
Compressor Housing: .60 A/R
Turbine Wheel Inducer: 53mm
Turbine Wheel Exducer: 41.7mm
Turbine Wheel Map: Maps
Turbine Housing: Externally gated, V-band Inlet & V-band Outlet, and .64 A/R
APPLICABLE GARRETT PART NUMBERS:
466541-5001S
466541-0001
466541-1
466541-5004S
466541-0004
466541-4
Specifications
- Part Number: 466541-5001S, 466541-0001, 466541-1, 466541-5004S, 466541-0004, 466541-4
- Brand: Garrett
- Type of Part: GT Ball Bearing
- Length: 10.0
- Width: 12.0
- Height: 12.0
- Weight: 25.000000
