Garrett GT2560R (170-270 HP)
1,021.14€
Sold By: Baltic Turbo Motors
Horsepower: 170 - 270 Displacement: 1.4L - 2.2L Turbo Reference Data Compressor Turbine Turbo PN CHR
SKU: GAR-836023-5004S
Categories: Performance Parts
Share:
Horsepower:
170 - 270
Displacement:
1.4L - 2.2L
| Turbo Reference Data | Compressor | Turbine | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Turbo PN | CHRA | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | A/R |
| 836023-5004S | 835995-0003 | 46mm | 60mm | 60 | 0.80 | 53mm | 42mm | 62 | 0.64 |
Features:
- Original GT series aerodynamics.
- Internally wastegated turbine housing.
- Sold as a complete turbo (includes turbine kit & actuator).
- Ball bearing configuration with water cooled CHRA.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
