The FP54 Green is a torque monster due to its smaller 65MM TD06 turbine wheel and ultra responsive 7
SKU: FP-54GREEN-BB-EVO9-1
Categories: Performance Parts
Share:
The FP54 Green is a torque monster due to its smaller 65MM TD06 turbine wheel and ultra responsive 73MM HTA compressor wheel. Features a new, 9-blade FP54 turbine wheel paired with a 73 HTZ compressor wheel to make a quicker spooling Green that still flows 57LB per minute. It even comes in a 10.5 MHI housing so it’s a stock location, bolt-on solution.
Compatible with these models:
Mitsubishi Evolution IV V VI VII VIII IX
Please review all options before purchase!
There is a lot of information on this page. These turbos are available with the journal bearing or ball bearing CHRA and only offered with the Mitsubishi housing only. The MHI housing will work with factory-style o2/downpipe and uses an Evo 9 style actuator. The stock Evo 8 actuator will not work. The FP54 is not available with the stainless housing.
FP54 Green Evo IX Turbo
FP Part Numbers:
2005000, 2005002, 2005004, 2005100, 2005102, 2005104
Compatible with these models:
Mitsubishi Evolution IV V VI VII VIII IX
Please review all options before purchase!
There is a lot of information on this page. These turbos are available with the journal bearing or ball bearing CHRA and only offered with the Mitsubishi housing only. The MHI housing will work with factory-style o2/downpipe and uses an Evo 9 style actuator. The stock Evo 8 actuator will not work. The FP54 is not available with the stainless housing.
FP54 Green Evo IX Turbo
FP Part Numbers:
2005000, 2005002, 2005004, 2005100, 2005102, 2005104
The Mitsubishi MHI Turbine Housing | |
MITSUBISHI 10.5 MHI HOUSING |
| Bolts to stock exhaust manifold or aftermarket factory-placement manifold with Mitsu flange. |
| Fits factory o2 housing and downpipe or any stock placement aftermarket o2 housing and downpipe combo. |
| Uses Evo 9 Style Internal Wastegate. (Available with purchase.) |
| Recommended Options for Install: • • • |
| Manifold Gasket (Not Included) • • |
What's the difference between Journal Bearing and Ball Bearing? | ||
FP 54Green: | Journal Bearing: | Ball Bearing: |
| CHRA: | FP Journal Bearing | Xona Rotor Dual Ceramic BB |
| Oil Line: | NOT Included. Required for Install. NOT compatible with stock feed lines. NEW FP JB Feed Line is (.) | NOT Included. Required for Install. Compatible with stock feed lines! (Optional) NEW FP SS Feed Line is (.) |
| Compressor Wheel: | 73HTZ | 73HTZ |
| Flow Rating: | 57 lb Per Minute | 57 lb Per Minute |
| Compressor Wheel Inducer: | 52.6mm | 52.6mm |
| Compressor Wheel Exducer: | 73mm | 73mm |
| Turbine Wheel Inducer: | 60.8mm | 60.8mm |
| Turbine Wheel Exducer: | 54mm | 54mm |
| Compressor Housing: | 84mm Flow Advancement Port Cover | 84mm Flow Advancement Port Cover |
Black Ceramic Coating (+$100): | ||
| (Stainless housing is pictured, but please note the FP54 is not available with the stainless housing. MHI only.) You can have your MHI housing treated with a black ceramic coating to help keep the heat in, keeping your engine bay cooler and it will look amazing! | ||
