AutoMeter 52mm Elite Digital Stepper Motor 0-100 PSI Oil Pressure Gauge (5652)

The life blood of your engine, a lack of oil pressure is one of the most catastrophic scenarios that can happen. Knowing the precise pressure using an oil pressure sensor is critical to both its longevity and performance, as well as your peace of mind. AutoMeter’s Digital Stepper Motor Oil Pressure Gauge utilizes the most advanced technology on the market to deliver accuracy and durability you won’t find anywhere else. Our advanced 1/8” NPT solid state pressure transducer (included) provides the best possible measurements with unparalleled resistance to vibration and heat. A direct plug in wiring harness is also included for ease of installation and data logging is available thanks to a .5 - 4.5v analog output.

Vehicle Fitment:
Universal Product

Features:
• 7 user selectable colors (blue, white, red, green, cyan, violet, and yellow) to match visual preferences of driver and visibility conditions
• Built-in Pro-Control circuits with custom programmable activation/ deactivation points for key functions like lights, fans, switches, and pumps allow drivers to focus on the competition while the gauges control key vehicle systems
• Set custom alert High and Low points specific to your vehicle and receive full dial warning notification to highlight the need for driver attention
• Acquire data for later review with one-touch Peak Recall functionality
• Data logger 0-5V output provides ECU and data systems with vital information
• Gauge kit includes 1/8” NPT stainless steel pressure transducer, 1/4” NPT adapter, wiring harness, mounting hardware, and detailed instructions for installation
• 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
• AutoMeter’s race proven digital stepper motor electric instruments provide unmatched accuracy while keeping hazardous fluids outside of the vehicle T
• he accuracy of digital stepper motor gauges is further increased by utilizing a self calibration sequence during power up

Ships With:
• Includes Sending Unit (Part Number 2246)
• 3/8' NPT and 1/2' NPT adapter fittings
• Wire Harness (Part Number 5275)
• Gauge Bracket Kit (Part number 2230)

Specs:
Size: 2-1/16' (52.4mm)
Type: Digital Stepper Motor
Range: 0-100 PSI
Lighting: LED
Illumination: 7 selectable color options (blue, white, red, green, cyan, violet, and yellow)
Gauge Face: Black
Gauge Bezel: Silver
